Give in to the Groove

Product details

About

The award winning AMG 12J2 12” tonearm features our patented dual-pivot bearing.

Specifications


Bearing:

Dual-pivot design instead of standard gimbaled bearing
Vertical bearing technology inspired the technique used stabilize the rotor heads of helicopters
Uses two 0.5 milimeter thick spring steel wires allows for fine azimuth adjustment while eliminating bearing play
Horizontal axle made from hardened tool steel, precision ground to a backlash-free fit with needle bearing
Extremely precise and maintenance free
Armwand:

Aircraft-grade aluminum
Anodized aluminum tube controls resonance
12 gram effective mass
Counterweight:

2-piece with Teflon-decoupled sleeve
Copper Internal Wiring:

Multiple gauges of high quality copper
Magnetic Anti-skating:

Decoupled via ring magnet and 2 bar magnets
Magnetic fields isolated in a patented bearing housing
VTA:

Precision locking system allows for easy adjustment
Specifications:

Effective Length: 304.8mm
Pivot to Spindle Length: 291.4mm
Overhang: 13.4mm
Offset Angle: 17.89 degrees
Effective Mass: 12.2 grams
Null Points: Inner: 66.04mm, Outer: 120.9mm
